Animatronic

The Animatronic is a puppet which can be positioned or animated. By default, the animations will be looking rusty. This can however be changed.

The maximum rotation of every body part is 180° positive or negative.

Example

In order to use the Animatronic, a modem needs to be placed below it. Said modem can then be connected as usual.

Once connected, it can directly be called and used in the code:

local animatronic = peripheral.find("animatronic")

-- Make it stand normally rather than hanging,
-- like it does by default.
animatronic.setHeadRot(0,0,0)
animatronic.setLeftArmRot(0,0,0)
animatronic.setRightArmRot(0,0,0)

-- We also need to apply the changes,
-- after we configured it like above.
animatronic.push()

Note that transitioning from the previous pose to the new one takes about 1 second, with the exception if the transition type is set to none, where it instead will be switching instant:

local animatronic = peripheral.find("animatronic")

animatronic.setTransition("none")

-- ...

---

Metadata

Peripheral	v1.1
Attach name	"animatronic"
Attach side	only "top"

---

API

setFace(face)

Changes the face of the Animatronic.

Parameters

1. face: string The new face. Must be either "normal", "happy", "question" or "sad".

Throws

1. Whenever the given string is not one of those types.

---

setTransition(kind)

Sets the Animatronic's animation transition mode.

Parameters

1. kind: string The new transition mode. Must be either "linear", "none" or "rusty".

Throws

1. Whenever the given string is not one of those types.

---

push()

Pushes the stored rotation values to the Animatronic. After pushing them, every rotation gets reset to 0.

---

setHeadRot(x, y, z)

Sets the head rotation. Can only be set within the bounds -180° to 180° for x, y and z.

Parameters

1. x: number The x rotation.
2. y: number The y rotation.
3. z: number The z rotation.

---

setBodyRot(x, y, z)

Sets the body rotation. Can only be set within the bounds -180° to 180° for y and z.

Info

x can be set to any number within 360°.

Parameters

1. x: number The x rotation.
2. y: number The y rotation.
3. z: number The z rotation.

---

setLeftArmRot(x, y, z)

Sets the left arm rotation. Can only be set within the bounds -180° to 180° for x, y and z.

Parameters

1. x: number The x rotation.
2. y: number The y rotation.
3. z: number The z rotation.

---

setRightArmRot(x, y, z)

Sets the right arm rotation. Can only be set within the bounds -180° to 180° for x, y and z.

Parameters

1. x: number The x rotation.
2. y: number The y rotation.
3. z: number The z rotation.

---

getStoredHeadRot()

Returns the current stored head rotation.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getStoredBodyRot()

Returns the current stored body rotation.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getStoredLeftArmRot()

Returns the current stored left arm rotation.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getStoredRightArmRot()

Returns the current stored right arm rotation.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getAppliedHeadRot()

Returns the rotation of the head.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getAppliedBodyRot()

Returns the rotation of the body.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getAppliedLeftArmRot()

Returns the rotation of the left arm.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation

---

getAppliedRightArmRot()

Returns the rotation of the right arm.

Returns 1. number The x rotation 2. number The y rotation 3. number The z rotation
